Direct Cooking
Direct Cooking System consists of concentrating reflectors that move to track the movement of the Sun. In STRE Direct Cooking System the reflected and concentrated Sunlight enters a nearby kitchen directly to strike a cooking pot or frying surface. Each morning, the operator rotates the concentrating reflector back to a starting position in which the reflected beam is aligned with the axis of rotation of the reflector, and starts the Tracking mechanism (Electronic). Every few days the operator adjusts the angle between the axis of rotation and the concentrating reflector to accommodate the seasonal variation in the height of the Sun. Once the reflected beam is aligned with the axis of rotation of the concentrating reflector and the timer is in motion, the reflected beam remains aligned with the axis of rotation all day. The reflecting surface of the concentrating reflector consists of a number of facets, usually flat Al. glass mirrors. A concrete pad and a welded steel space frame provide support for the concentrating reflector. The area of the concentrating reflectors in the configurations shown above is usually about 10 m2 or 16 m2.
